● CATL Premium Cells Inside
● Long lifespan： Up to 6000 cycles
● Advanced BMS Control (W/ Active Balance)
● Slim & Steady Design
● Communication: CAN/ RS485 / Dry Contact / WiFi (WiFi Stick Optional) communication support
● Multi-parallel Configuration, up to 16sets (163.84 kWh)
● Compatible with mainstream brand inverters: Growatt, Deye, Victron, Aiswei, Afore, SRNE, MEGAREVO…
● Certifications of UL 1973, UL 9540A, UN38.3, RoHS, REACH and TUV approvals
Capacity :
10.24kWhNominal Voltage :
51.2 VRated Capacity :
200AhCycle Life :
≥6000Dimensions (H*W*D) :
550*165*867mmWarranty :
10 Years
UIENERGIES 51.2V 200Ah 10kWh CATL Battery Energy Storage System BESS
The TYPL Powerwall is a compact home battery that reduces your reliance on the grid by storing your solar energy for use when the sun isn’t shining. You can add additional Powerwall units to your system to reduce your impact further and better prepare your home for power outages.
Key Features
High Safety:
Our state-of-the-art BMS ensures that UIENERGIES Powerwall batteries are monitored, controlled and protected. You can count on it for a worry-free energy storage experience.
Longevity :
UIENERGIES Powerwall battery With a life cycle of up to 6000 cycles, it's a smart investment for the long term.
Sustainability:
Do your part to reduce your carbon footprint. UIENERGIES Powerwall Lithium Batteries promote cleaner energy use and contribute to a more sustainable environment.
Energy Independence:
Harnessing the power of the sun! Use the fast-charging feature of UIENERGIES Powerwall LiFePO4 Lithium Batteries to store excess solar energy during the day and use it at night.
| TYPL-10K | TYPL-10K-UL | |
| Battery Type | CATL | |
| Rated Capacity | 200 Ah | |
| Nominal Voltage | 51.2 V | |
| Capacity | 10.24 kWh | |
| Rated Charging / Discharging Current | 0.6C, 120 A | |
| Max. Discharge Continuous Current | 0.6C, 120 A | |
| Battery Max. Charge / Discharge Power | 6.14 kW / 6.14 kW | |
| Peak Discharge Current / Power | 160 A/ 8.19 kW, 1 min. | |
| Available SOC Range | 0% ~ 100% 90% DOD is recommended |
|
| Dimensions | 550*165*867mm | 550*165*1000mm |
| Weight | 94 kg | 98kg |
| Operating Temperature | Charging Temperature:-5°C~ 55°C/123°F~ 131 °F Discharge Temperature:-15°C~ 55°C/5°F ~ 131 °F |
|
| Storage Temperature | -15°C~ 55°C/ 5°F~ 131 °F | |
| Working Humidity | 5 ~ 95% RH (Non-Condensing) | |
| Altitude | ≤2000 m/ 6562 ft | |
| Communication | CAN/ RS485 / Dry Contact / WiFi (WiFi Stick Optional) |
|
| Cycle Life | 6000 | |
| Warranty | 10 Years | |
| IP Rating | IP65 | |
| Certification | TUV / IEC 62619 / IEC 62040/ UN38.3/ RoHS / REACH/ UKCA /CEC | UL1973/ UL 9540A/ UN 38.3/TUV/ RoHS/ REACH |
Product Structure Diagram
Wide Compatibility
Compatible with mainstream brand inverters: Growatt, Deye, Victron, Aiswei, Afore, SRNE, MEGAREVO…
Production Process
Product Cases
● High Safety：A+ grade high-quality LiFePO4 lithium battery ● Advanced BMS Control： BMS management system protection, safety first ● Communication: RS485, CAN, RS232 communication support ● Modular design allowing extension, maximum Number Of Combinations /Total Power: ×15(76.8kWh) ● Compatible with mainstream brand inverters: Growatt, Deye, Victron, Aiswei, Afore, SRNE, MEGAREVO… ● Remote access with Bluetooth / WiFi for monitoring, to reduce operation and maintenance costs ● Floor-standing/Wall-mounted, convenient and easy installation
Learn More
● High Safety：LiFePO4 technology makes our batteries the safest available ● Easy to Expand: Multi-parallel Configuration, up to 15sets (153.6 kWh) ● Long Life：≧6000 cycles ● Buit-In BMS：Ultra safe Built-in BMS protection ● Matching Inverter Brands: Deye, Luxpower, Senergy, SMA, Solis,etc... ● Remote access with Bluetooth / WiFi for monitoring, to reduce operation and maintenance costs ● Floor-standing/Wall-mounted, convenient and easy installation
Learn More
● CATL Premium Cells Inside ● Long lifespan： Up to 6000 cycles ● Advanced BMS Control (W/ Active Balance) ● Slim & Steady Design ● Communication: CAN/ RS485 / Dry Contact / WiFi (WiFi Stick Optional) communication support ● Multi-parallel Configuration, up to 16sets (163.84 kWh) ● Compatible with mainstream brand inverters: Growatt, Deye, Victron, Aiswei, Afore, SRNE, MEGAREVO… ● Certifications of UL 1973, UL 9540A, UN38.3, RoHS, REACH and TUV approvals
Learn More
● Use CATL Cells ● Cycle Life :≥6000 ● Advanced BMS Control ● Remote control system for APP, visual data ● Featuring multiple communication interfaces - CAN/ RS485 / Dry Contact / WiFi (WiFi Stick Optional) ● Maximum Number Of Combinations / Total Power: ×16(163.84 kWh) ● Compatible with mainstream brand inverters: Growatt, Deye, Victron, Aiswei, Afore, SRNE, MEGAREVO… ● Certifications of UL 1973, UL 9540A, CEC, UN38.3, RoHS, REACH, IEC 62619, IEC 62040, TUV and UKCA approvals.
Learn More
● High Safety：A+ grade high-quality LiFePO4 lithium battery ● Long Life: ≧6000 cycles ● Built-in BMS: Smart Management system ● Communication: RS485, CAN communication support ● Modular design allowing extension, maximum Number Of Combinations /Total Power: ×16 ● Certification: IEC62619 / UL1973 / UL9540A / CE-EMC / UN38.3 / FCC
Learn More
● High Safety：The use of the most advanced lithium iron phosphate battery core technology ● Easy to Expand: Multi-parallel Configuration, up to 16sets (81.92kWh) ● Long Life：≧6000 cycles ● Buit-In BMS：Ultra safe Built-in BMS protection ● Remote access with Bluetooth / WiFi for monitoring, to reduce operation and maintenance costs ● Certification: IEC62619 / UL1973 / UL9540A / CE-EMC / UN38.3 / FCC
Learn More
● High Safety：The use of the most advanced lithium iron phosphate battery core technology ● Easy to Expand: Multi-parallel Configuration, up to 16sets (81.92kWh) ● Long Life：≧6000 cycles ● Advanced BMS Control ● Compatible with mainstream brand inverters: Victron/SMA/Goodwe/Imeon/Solis/SAJ/Growatt/Luxpower/Voltronic/Deye etc.
Learn More
● CTP (Cell To Pack) Technology ● Fully automated thermal management system ● Lithium iron phosphate battery ● Long lifespan ≧10000 cycles ● Long warranty : Ten-year warranty
